Goals of this presentation

Take home something you can use

Template enables type safety
Template is performant
Template enable generic programming

Goals of this presentation

Template doesn't need to be complicated

Presentation philosophy

Teach by examples
Explain the feature used in the examples
Warn about common pitfalls

Nicolai Josuttis, Back To Basics: Templates, CppCon 2022

https://youtu.be/HqsEHG0QJXU

[1:25 — 3:05]

Templates are a huge topic, and you could easily spend days on them. So, given the goals of this talk and the time I have, I settled on the following philosophy.

I like to keep things simple, so I'm going to show you a lot of examples. And at the end of the presentation, we'll look at three examples taken from production code.

To make sure those examples make sense to you, I'll explain, from the basics, every feature they use. Because of the time constraint, I won't be able to go further than that.

And of course, this is a Back to Basics talk, so I'll also point out the common mistakes people make with these features.

After this talk, I'd really encourage you to watch Nicolai Josuttis's recording. He gave a talk with the same title, and he goes into much more detail than I will today.

⏰ Agenda of today ⏰

Syntax & function templates
Implicit requirements
Template argument deduction
Variadic templates & perfect forwarding
Class templates
3 production code examples

Template syntax

A template defines a family of functions, classes, type aliases, variables or concepts.

template< [parameter-list] >
recipe

parameter-list can be:

type parameter e.g. std::string
non type parameter (aka NTTP) e.g. enum value, constexpr value
parameter pack using ellipsis ...
template parameter e.g. template<typename> class

recipe can be:

function definition
a class/struct definition
a type alias definition
variable definition
concept definition

Function template

Defines a family of functions

template<typename Swappable>
void mySwap(Swappable& a, Swappable& b) {
	Swappable tmp = std::move(a);
	a = std::move(b);
	b = std::move(tmp);
}

💡 Give good name to template parameters

⚠️ The compiler does not produce any code if the template is not instantiated

[1:10 — 5:25]

Let's define our first family. Here I'm showing a function template that defines a family of swap functions for different types.

To tell the compiler that we expect a type parameter, we use the keyword typename followed by a template parameter identifier. Notice that it is not T.

Then we can use that identifier to declare function parameters in our function signature or we can also use that identifier to declare an instance of that type in our function.

This really looks like a function but the difference with a normal function is that some types are not known at the time of writing the function. Those are the template parameters.

Because the types are not known, the compiler does not produce any code at this stage. We need to instantiate the template.

Function template

Defines a family of functions

template<typename Swappable>
void mySwap(Swappable& a, Swappable& b) {
	Swappable tmp = std::move(a);
	a = std::move(b);
	b = std::move(tmp);
}

int a = 5, b = 10;
mySwap(a, b);
assert(a == 10 && b == 5);

float c = 3.14f, d = 2.71f;
mySwap(c, d);
assert(c == 2.71f && d == 3.14f);

⚠️ Calling the function with 2 different types fails

float f = 3.14f;
int i = 42;
mySwap(i, f); // ❌ Does not compile

Function template

Defines a family of functions 🔎

cppinsights.io/s/b05df164

Source:

template<typename Swappable>
void mySwap(Swappable& a, Swappable& b) {
	Swappable tmp = std::move(a);
	a = std::move(b);
	b = std::move(tmp);
}

int a = 5, b = 10;
mySwap(a, b);

float c = 3.14f, d = 2.71f;
mySwap(c, d);

Insight:

template<>
void mySwap<int>(int& a, int& b)
{
	int tmp = std::move(a);
	a = std::move(b);
	b = std::move(tmp);
}

template<>
void mySwap<float>(float& a, float& b)
{
	float tmp = std::move(a);
	a = std::move(b);
	b = std::move(tmp);
}

⚠️ The compiler generates code for each instantiation.

https://cppinsights.io/s/b05df164

Function template

How are function templates compiled?

Two-phase name lookup

template<typename Swappable>
void mySwap(Swappable& a, Swappable& b) {
	Swappable tmp = std::move(a);
	a = std::move(b);
	b = std::move(tmp);
}

int a = 5, b = 10;
mySwap(a, b);

First, the compiler checks for syntax and resolve non-dependent names identifier.

Second the template argument is substituted in for the template parameter

⚠️ The code can compile until a function template is called

Function template

Implicit requirements

Implicit requirements are the sets of operations and properties that a type must support for the template to compile

template<typename T>
void mySwap(T& a, T& b) {
	T tmp = std::move(a);
	a = std::move(b);
	b = std::move(tmp);
}

What are the implicit requirements for the type T?

🙋‍♂️🙋‍♀️

Must be move constructible i.e have a valid T(T&&) constructor
Must be move assignable i.e have a valid T& operator=(T&&) assignment operator

💡 C++ 20 formally defines the requirement via the swappable concept.

💡 Before C++20, document the requirement explicitly using comments.

ℹ️ There are numerous possible implicit requirements

For instance:

T must have a public class member variable T.data
T must have a function member T::fun(int)
T must have a nested type T::TYPE
T must have a static function member

👉 Implicit requirement is a very important notion 👈

[1:40 — 10:05]

This brings us to one of the most important notions of this talk. Implicit requirements. The implicit requirements are the set of operations that a type must support for the template to compile. "Implicit" because they are not stated in the template's signature but are hidden in the body of the template.

Let's see if you have followed what I said until now. Can anyone tell me what are the implicit requirements of the `mySwap` template?

T must be move constructible from line 3 and must be move assignable from line 4 and 5.

When implicit requirements aren't met this is the point where the compiler will generate an error, often with messages that can be difficult to decipher.

Fortunately from C++ 20, we can use concepts to explicitly specify these requirements. I invite you to follow the talk of Amir Kirsh on Friday.

If you are not using C++20, I seriously recommend you to write the implicit requirements as a comment in the code.

It is to be noted that there are plenty of different implicit requirements, for instance...

Template argument deduction

General

Templates argument are deduced from the function arguments

For instance

template<typename T>
T myMax(T a, T b) {
	return a > b ? a : b;
}

void fun() {
	int a = 5, b = 4;
	auto c = myMax(a, b);
	static_assert(std::is_same_v<decltype(c), int>);
}

Calling myMax(a, b) deduces T = int

Template argument deduction

Type deduction

Another example

template<typename T>
T myMax(T a, T b) {
	return a > b ? a : b;
}

void fun() {
	auto c = myMax(5.1, 5.2);
}

What does T deduced to ?

🙋‍♂️🙋‍♀️

double

Template argument deduction

Explicit template arguments

Provide the template argument explicitly to override deduction

template<typename T>
T myMax(T a, T b) {
	return a > b ? a : b;
}

void fun() {
	auto c = myMax<float>(5.1, 5.2);
}

⚠️ Template arguments are never deduced from the return type ⚠️

template<typename T>
T parse(const std::string& text);

int i  = parse("42");      // ❌ Does not compile
auto i = parse<int>("42"); // 👍

[1:05 — 12:45]

If you don't want what deduction gives you, you can override it: write the template argument explicitly. `myMax<float>(5.1, 5.2)`. Now `T` is `float`, deduction is skipped entirely, and the `double` literals are converted at the call.

Explicit arguments always win. Deduction only fills in what you did not specify.

(fragment) Now a rule that catches everybody at least once: template arguments are *never* deduced from the return type. Look at `parse`. Writing `int i = parse("42")` does not compile — the compiler does not look at what you are assigning to. Deduction works left to right, from the arguments in. You must write `parse<int>("42")`.

And remember this, because it comes back in the second half: some templates can *only* be called with explicit arguments.

Template argument deduction

How `cv qualifiers` are deduced

One question decides everything: is the parameter a reference or not?

template<typename T>
void funcValue(T a);

template<typename T>
void funcRefParam(T& a);

int x = 5;
const int cx = 5;

funcValue(x);  // T is deduced as int
funcValue(cx); // T is deduced as int (const is dropped)

funcRefParam(x);  // T is deduced as int
funcRefParam(cx); // T is deduced as const int (const is kept)

⚠️ A const T& parameter drops it again

template<typename T>
void funcConstRefParam(const T& a);

funcConstRefParam(cx); // T is int, but a is still const int&

💡 Rule of thumbs 💡

By value → cv-qualifiers are dropped
By reference → cv-qualifiers are preserved

Template argument deduction

Arrays and pointers

template<typename T>
void funcValue(T arg);

template<typename T>
void funcRefParam(T& arg);

int arr[5];
int* ptrArr = arr;

// the pointer remains a pointer
funcValue(ptrArr); // T is deduced as int*

// the reference keeps the int* type
funcRefParam(ptrArr); // T is deduced as int*. But arg is now int*& (dangerous)

// the array decays to a pointer, the size is lost
funcValue(arr);    // T is deduced as int*

// the reference keeps the array type
funcRefParam(arr); // T is deduced as int[5]

💡 A reference parameter can even deduce the size as an NTTP 💡

template<typename T, std::size_t N>
constexpr std::size_t arraySize(T(&)[N]) { return N; }

int arr[5];
static_assert(arraySize(arr) == 5);

[1:10 — 14:40]

Let's see now how template argument deduction works with arrays and pointers.

Again we are using the same example function that takes its parameter either by value or by reference.

On the right side we are defining an array and a pointer to it, and then observing how the template argument deduction behaves for each case.

let's start first with the pointer

Whenever we pass the pointer by value, it remains a pointer. If we pass it by reference, the reference keeps the pointer type.

If we pass the array by value, it decays to a pointer and the size information is lost. If we pass it by reference, the array type is preserved and the size remain.

The fact that the size remain is very beneficial because we can for instance deduce the size as an NTTP

Template argument deduction

⚠️ Why `T&` is dangerous with pointers ⚠️

A reference parameter will happily deduce T as a pointer type.

template<typename T>
void dangerous(T& retry) {
	// ... some logic
	++retry;
}

int retries = 0;
int* retriesPtr = &retries;

// 😱 Forgot the '*' 😱
dangerous(retriesPtr); // T is int*, so retry is int*&
// retriesPtr is now pointing to an invalid memory address
printf("%d\n", *retriesPtr);   // 💥 disaster 💥

The pointer is incremented, not retries

⚠️ Think twice before using a non-const reference parameter
💡 Validate the deduced type with static_assert and <type_traits>, e.g. std::is_pointer_v, std::is_const_v
💡 From C++20, use concepts

When the deduced type surprises you

A generic `myMax`

template<typename T>
T myMax(T a, T b) {
	return a > b ? a : b;
}

What does the following call return? 🤔

myMax("hello", "world");

🙋‍♂️🙋‍♀️

We don't know the result 🤷‍♂️. Pointer comparison

The instantiated function is

const char* myMax(const char* a, const char* b) {
	return a > b ? a : b;
}

When the deduced type surprises you

Fix: Provide a function overload

A non-templated overload function gives a custom implementation for a specific type.

const char* myMax(const char* a, const char* b) {
	return std::strcmp(a, b) > 0 ? a : b;
}

Now myMax("hello", "world") returns the pointer to "world" 👍

💡 Out of reach for a macro: the pre-processor cannot overload 💡

Putting templates to work

Generic programming

Iterate over any kind of iterables

template<typename Iterable>
void print(Iterable& c) {
	for (const auto& element : c) {
		std::cout << element << "\n";
	}
}

Works with

Any standard containers (vector, list, set, map, ...)

std::vector<int> v = {1, 2, 3};
print(v);

C++ 20's span and ranges

std::span<int> s = {v};
print(s);

std::vector<int> v = {1, 2, 3, 4, 5};
auto even = v | std::views::filter([](int n) { return n % 2 == 0; });

print(even);

C-style arrays

int arr[] = {1, 2, 3};
print(arr);

Custom types

struct Graph { ... };
// Make Graph printable by adding an overload for print
void print(Graph& g) { ... }

Graph g;
print(g); // 👍

Extensible without ever touching print 👍

Putting templates to work

"Polymorphism" without inheritance

Polymorphic behaviour between unrelated types

template<typename T>
constexpr int legs(T& ll) { return ll.legs(); }

struct Cow {  // not in any class hierarchy
	constexpr int legs() { return 4; }
};

struct Duck { // not in any class hierarchy
	constexpr int legs() { return 2; }
};

int main()
{
	Cow c;
	Duck d;

	// resolved at compile time, no vtable, no common base
	static_assert(legs(c) == 4);
	static_assert(legs(d) == 2);
}

Example from Bjarne Stroustrup (apologies for the artificial example)

[1:10 — 19:05]

Our second example is that templates can enable a sort of polymorphic behavior without requiring inheritance. It is an example that I read from a post of Bjane Stroustrup. But when I asked him the permission to use it, he said I need to mention his apology for this example because of the artificial nature of the example.

In practice, we create a function which calls a member function on any type that provides it, without requiring a common base class. This is an implicit requirement.

Now let's come back on the example.

We define a templated function legs that calls the legs member function on any type that provides it. This is the implicit requirements.

Now let's define 2 structs which implement the implicit requirements.

Finally we can see that the templated legs function calls the correct legs member function. The resolution happened at compile time.

Variadic templates

A variable number of template parameters

The ellipsis ... says which parameter is a pack, and where it expands.

template<typename T, typename ...Ts>
T sum_all(Ts... args) {
    std::array<T, sizeof...(Ts)> arr = { args... }; // pack expansion fills the array
    return std::accumulate(arr.begin(), arr.end(), 0);
}

// Any number of arguments can be given to sum_all
auto total = sum_all<int>(1, 2); // total == 3

💡 T doesn't appears in any function parameter → it can only be given explicitly 💡

[1:45 — 20:50]

So far every template took a fixed number of parameters. Variadic templates lift that to a variable number.

The whole feature is one token: the ellipsis, three dots. It has exactly two jobs, and once you see them you can read any variadic code.

But before we dive into the detail, let's have a look at our next example.

The responsibility of the sum_all function will be to sum all the arguments passed to it. This function takes 2 template parameters: the type of the accumulator (`T`) and a variadic pack of argument types (`Ts...`).

Now let's talk about the job of the ellipsis. Job one — to the *left* of a name, in a declaration: "this is a pack". `typename ...Ts` declares a pack of types. `Ts... args` declares a pack of function arguments.

Job two — to the *right* of an expression: "expand the pack here". We see it expanded in the function arguments as well as in the initialization of the std::array.

Declare on the left, expand on the right. That is genuinely the whole rule.

Regarding its call, we need to explicitly specify what T is. That's because T isn't part of the function parameters and so it must be given explicitly.

Variadic templates

sum_all under the hood 🔎

What the pack expansion really generates

cppinsights.io/s/b7e622a8

Source:

template<typename T, typename ...Ts>
T sum_all(Ts... args) {
	std::array<T, sizeof...(Ts)> arr = {args...};
	return std::accumulate(arr.begin(), arr.end(), 0);
}

auto total = sum_all<int>(1, 2);

Insight:

template<>
int sum_all<int, int, int>(int __args0, int __args1) {
	std::array<int, 2> arr = {{__args0, __args1}};
	return std::accumulate(arr.begin(), arr.end(), 0);
}

auto total = sum_all<int>(1, 2);

https://cppinsights.io/s/b7e622a8

⚠️ If sum_all is called with 3 arguments a new version is generated

Variadic templates

C++17's fold expressions

Syntax

(pattern op ...);

A fold repeats one expression for each element of the pack.

template<typename ...Args>
void print(Args... args) {
	((std::cout << args << " ") , ...);
}

Calling print(1, 2.5, "hello") prints 1 2.5 hello

ℹ️ Before C++17 you peeled the pack off one argument at a time, with a recursive overload and a non-template base case

Variadic templates

Under the hood: one call per pack element 🔎

cppinsights.io/s/16760da2

Source:

template<typename ...Args>
void print(Args... args)
{
	((std::cout << args << " ") , ...);
}

print(1, 2.5, "hello");

Insight:

template<>
void print<int, double, const char *>(int __args0,
                                       double __args1,
                                       const char * __args2)
{
	(std::cout << __args0 << " "),
	(std::cout << __args1 << " "),
	(std::cout << __args2 << " ");
}

print(1, 2.5, "hello");

https://cppinsights.io/s/16760da2

https://en.cppreference.com/cpp/language/fold

Perfect forwarding

Passing arguments on to another function while preserving their value category (lvalue or rvalue).

template<typename Args>
void relay(Args&& args) {
	consume(std::forward<Args>(args));
}

Textbook example: `std::vector::emplace_back`

template<typename ...Args>
reference emplace_back(Args&&... args);

push_back builds a temporary, then moves it

users.push_back(User{2, "Bob"});

emplace_back calls the constructor in place

users.emplace_back(2, "Bob");

https://godbolt.org/z/334GsGa4n

[1:45 — 25:10]

One more building block we need to go over is perfect forwarding.

The problem: you have a wrapper that takes arguments and passes them to another function. If you do it naively you lose information — specifically the *value category*. A temporary that arrived as an rvalue, ready to be moved from, becomes a named lvalue inside your function and gets copied instead. You silently turned a move into a copy.

`std::forward` fixes that. Take the parameter as `T&&` where `T` is deduced, and forward it. If the caller passed an lvalue, `consume` sees an lvalue; if an rvalue, `consume` sees an rvalue. Perfectly preserved — hence the name.

(fragment) The textbook example is `emplace_back`. Its signature is a variadic pack of forwarding references.

Compare the two calls. `push_back(User{2, "Bob"})` constructs a temporary `User`, then moves it into the vector, then destroys the temporary. `emplace_back(2, "Bob")` forwards the raw arguments all the way down and constructs the `User` *directly in the vector's storage*. One object instead of two. No move, no destructor call. Notice that emplace_back takes the constructor arguments as parameters and not a constructed object like push_back.

The godbolt link below shows that in the push_back case, a temporary is created and then moved away while in the emplace_back case, only the constructor is called.

Perfect forwarding

The `std::forward` Catch

std::forward only works on a forwarding reference: a T&& where T is deduced by this very function.

template <typename T>
void relay(T&& arg) {
	consume(std::forward<T>(arg));
}

⚠️ These are not forwarding references ⚠️

void relay(std::vector<int>&& arg); // fixed type

template<typename T>
void relay(const T&& arg);          // const rvalue

Two more traps:

⚠️ Using arg again after forwarding it → moved-from bug
⚠️ std::move instead of std::forward → moves lvalues unconditionally

Forwarding references are also called universal references: Scott Meyers

[1:55 — 27:05]

Here is the catch.

`std::forward` only does its job on a genuine *forwarding reference*. And a forwarding reference is very precisely defined: a `T&&` where `T` is a template parameter deduced *by this very function*. Both halves matter — I have highlighted them.

It is very confusing because it looks like a plain rvalue reference, but it is actually a forwarding reference. Just because it is a template parameter.

(fragment) These are *not* forwarding references, even though they have two ampersands. The first takes a fixed type — that is a plain rvalue reference; it only binds to rvalues, nothing is deduced. The second is `const T&&` — the `const` disqualifies it. The pattern has to be exactly `T&&`.

(fragment) Two more traps. One: after you forward an argument, treat it as moved-from. Using it again is a bug — and a quiet one, because a moved-from object is valid, just unspecified. Two: don't reach for `std::move` instead of `std::forward` here. `move` casts unconditionally, so it will steal from a caller's lvalue that they still intend to use. `forward` moves only when the caller gave you an rvalue.

Rule of thumb: `std::move` on a concrete rvalue reference, `std::forward` on a forwarding reference. Never cross them.

(fragment) Terminology note: Scott Meyers coined "universal reference" before the standard settled on "forwarding reference". Same thing, you will see both.

Class/struct template

Defines a family of classes

A class template describes one class blueprint that the compiler instantiates for each type.

template<typename T>
class Stack {
private:
	std::vector<T> data;
public:
	void pop() { data.pop_back(); }
	const T& top() const { return data.back(); }
	bool empty() const { return data.empty(); }
	std::size_t size() const { return data.size(); }

	template <typename ...U>
	void emplace(U&&... args) { data.emplace_back(std::forward<U>(args)...); }
};

Stack<int> intStack;
Stack<float> floatStack;

Stack<int> and Stack<float> are different types generated from the same template.

Because Stack<int> and Stack<float> are types, they can be given as template parameter values

[1:40 — 28:45]

Last building block: class templates. Everything you know about function templates carries over.

We are building a stack abstraction using a vector as an inner data structure. Let's go through the code step by step.

(lines 1-2) We tell the compiler we are building a templated class by using the keyword `template<typename T>` before the class definition.

(lines 3-4) `T` is usable anywhere inside — here as the element type of the underlying vector.

(lines 5-12) Ordinary member functions. T can be used anywhere as well. Notice also the function emplace which uses perfect forwarding to emplace the element in place into the vector.

(lines 15-16) Instantiate with `int` and with `float`.

(fragment) And here is the thing to internalise: `Stack<int>` and `Stack<float>` are different, unrelated *types*. Not two instances of one type — two types. You cannot assign one to the other. They have no common base class.

(fragment) And because they are types, they can themselves be used as template arguments. That is how you get `std::vector<std::vector<int>>` — and it is the mechanism behind CRTP, which is a few slides away. Types in, types out. Templates compose.

Perfect forwarding

The `std::forward` Catch reloaded

⚠️ Not all T&& are forwarding references

template <typename T> // T deduced HERE, at instantiation
class Stack {
	// ... other member functions ...

	// args looks like a forwarding reference but T is already fixed
	void emplace(T&&... args) { data.emplace_back(std::forward<T>(args)...); }
};

Example of instantiation: Stack<int> s;

struct Stack {
	// ... other member functions ...

	// ⚠️ Only accept rvalues references of type int
	void emplace(int&&... args) { data.emplace_back(std::forward<int>(args)...); }
};

Fix: make emplace templated

template <typename T>
struct Stack {
	// ... other member functions ...

	template <typename ...U>
	void emplace(U&&... args) {
		consume(std::forward<U>(args)...);
	}
};

[1:20 — 30:05]

You might wonder why `emplace` is templated and the answer lies in the forwarding reference rules.

Look at `emplace`. It takes `T&&`. There is a `typename T` right above it. It looks exactly like a forwarding reference. It is not.

Why? Because `T` is deduced at *class* instantiation — when you write `Stack<int>` — not by the member function. By the time anyone calls `emplace`, `T` is already fixed. And the rule says: deduced *by this very function*.

(fragment) To convince ourselves, let's look at what the compiler actually generates for `Stack<int>`. There it is in black and white: `void emplace(int&&...)`. The function only accepts r-value references. The bug is there but your code will compile.

(fragment — the fix box) The fix is one extra line: give the member function *its own* template parameter, `U`. Now `U` is deduced at the call, `U&&` is a real forwarding reference, and `std::forward<U>` behaves.

Class/struct template

Function member instantiation

void useStack() {
	Stack<int> s{};
	s.emplace(5);
	std::printf("%d\n", s.top());
}

https://godbolt.org/z/n7K1PKdrs

Only the called member functions are instantiated

⚠️ A member function that would not compile for T stays silent until someone calls it

Class/struct template

Curiously Recurring Template Pattern (CRTP)

A class can pass itself as the template argument when deriving from it.

ℹ️ The base class knows the type CHILD of the class deriving from it

template <typename CHILD>
struct Base {
	void greet() {
		static_cast<CHILD*>(this)->greet_impl(); // Base knows the derived type
	}
};

struct Derived : public Base<Derived> { // pass yourself as the argument
	void greet_impl() { std::puts("hello"); }
};

Derived d;
d.greet(); // prints "hello", no virtual call

💡 Static polymorphism, resolved at compile time 💡

[1:50 — 32:35]

The last technique of today is the Curiously Recurring Template Pattern (CRTP).

This allows a parent class to know the exact static type of the derived class.

Let's look at an example.

(lines 1-2) `Base` looks like a normal template class, but it takes a type parameter I have named `CHILD`.

(lines 3-5) Because we know that CHILD is the type of the derived class, we can safely cast `this` to `CHILD*` and call member functions on it.

(lines 8-10) Now let's define the derived class. It inherits from the base class and passes itself as the template argument. The derived class also implements the `greet_impl` function that the base class will call.

(lines 12-13) Let's now create an instance of the Derived class and call the greet function of the base class. Even though we call the base class function, a function of the derived class is invoked.

(fragment) This is static polymorphism with an inheritance *shape*: the base provides shared behaviour, the derived class provides the specifics, and it is all resolved at compile time.

(fragment) Say the key line again: the base class knows the type of the class deriving from it. That one fact is what makes the third example — the hardware register abstraction — possible. Keep it warm; we use it in about ten minutes.

Let's see templates in action

🚀🚀🚀🚀🚀🚀🚀

Generic serializer using a policy-based design

Design a dump_object function to serialize an object into different formats (e.g., JSON, YAML)
It should use policy classes (sinks) to determine the output format
No inheritance required
Easy to extend with new sinks without modifying the function itself

Generic serializer using a policy-based design

template <typename Sink>
void dump_object(const Object& d)
{
	Sink::begin_object("object");
	Sink::field("id", d.id());
	Sink::field("name", d.name());
	Sink::end_object();
}

struct JsonSink {
	static void begin_object(std::string_view n) {
		std::printf("\"%s\": {\n", n.data());
	}
	static void field(std::string_view k, int v) {
		std::printf("  \"%s\": %d,\n", k.data(), v);
	}
	static void field(std::string_view k, std::string_view v) {
		std::printf("  \"%s\": \"%s\",\n", k.data(), v.data());
	}
	static void end_object() { std::printf("}\n"); }
};

struct YamlSink {
	static void begin_object(std::string_view n) {
		std::printf("%s:\n", n.data());
	}
	static void field(std::string_view k, int v) {
		std::printf("  %s: %d\n", k.data(), v);
	}
	static void field(std::string_view k, std::string_view v) {
		std::printf("  %s: %s\n", k.data(), v.data());
	}
	static void end_object() {}
};

Main function

int main() {
	Object apple{1, "apple"};
	std::printf("---------JSON-----------\n");
	dump_object<JsonSink>(apple);
	std::printf("---------YAML-----------\n");
	dump_object<YamlSink>(apple);
}

https://godbolt.org/z/crqP67bTW

Output:

---------JSON-----------
"object": {
  "id": 1,
  "name": "apple",
}
---------YAML-----------
object:
  id: 1
  name: "apple"

[1:30 — 35:15]

Here is the whole thing. Eight lines at the top.

`dump_object` takes a `Sink` as a template parameter and calls static functions on it: `begin_object`, `field`, `end_object`. That is all. `Sink` is a *type*, not an object — there is no parameter, nothing is passed at run time.

The implicit requirements are: a static `begin_object`, a static `field` for each value type, a static `end_object`.

(fragment — JsonSink) Here is a sink that satisfies them, emitting JSON. Plain struct, static members, no base class, no virtual.

(fragment — YamlSink) And here is YAML. Note `end_object` is *empty* — YAML has no closing brace. With a virtual interface you would still pay for that call. Here it inlines to literally nothing.

(fragment — main + output) And main: same object, two formats, two lines. The output is on the right. Godbolt link if you want to poke at it.

In this case the decision happened at compile time and we didn't need to rely on any vtables.

Generic abstraction layer

Register bank manager

Register bank is used to program the hardware
2 set of registers bank exists: Active and Standby
Driver writes the standby bank using write(...)
- write takes an unspecified number of parameters
- In our case it is write(name, value)
Driver calls commit() to swap the active and standby banks
Bank-swap policy is decoupled from register access logic
The driver code is unaware of the active bank

[1:15 — 36:30]

Example two, straight out of embedded work: a register bank manager.

When programming the HW, we typically have to deal with active and standby banks of configuration registers. This allows the driver to write to the standby bank without affecting the currently active configuration.

We want to design a write function that the driver will use to update the standby bank. The function should be flexible enough to handle different register layouts for various peripherals and thus take an unspecified number of parameters.

We also want a commit function that swaps the active and standby banks atomically.

The bank-swap policy is decoupled from the register access.

And the driver is unaware of which bank is currently active.

Generic abstraction layer

Register bank manager

Driver code

int main()
{
	ActiveStandbyBank<MotorConfig> mgr(MotorConfig{});

	// Write to the current standby bank i.e bank 0
	if(!mgr.write("speed_rpm", 1500)) {
		std::cerr << "Cannot write speed_rpm\n";
	}
	if(!mgr.write("torque_limit", 80)) {
		std::cerr << "Cannot write torque_limit\n";
	}

	mgr.commit();

	// Now writing to bank 1 (the new standby bank)
	if(!mgr.write("speed_rpm", 1000)) {
		std::cerr << "Cannot write speed_rpm\n";
	}
}

class MotorConfig
{
private:
	struct Config { uint16_t speed_rpm = 0;
									uint16_t torque_limit = 0; };
	Config m_banks[2]{};
public:
	bool write(uint8_t bank_id, std::string_view field, uint16_t value)
	{
		if (field == "speed_rpm") {
			m_banks[bank_id].speed_rpm = value;
			return true;
		} else if (field == "torque_limit") {
			m_banks[bank_id].torque_limit = value;
			return true;
		}
		return false;
	}

	void commit(uint8_t bank_id)
	{
		// action to commit the bank
	}
};

[1:50 — 38:20]

Let's now have a look at how the driver code interacts with the register bank manager.

(line 3) Create an `ActiveStandbyBank` wrapping a `MotorConfig`. (lines 5-11) Write two fields by name. Look at what is *missing*: no bank index anywhere. (line 13) Commit. (lines 15-18) Write again — and this now goes to the other bank, automatically. The client never knew, and cannot get it wrong.

Also note the return value is propagated — `write` returns a `bool` and we check it. Hold that thought, it matters in a second.

HAL implementation, bottom. (line 1) A completely plain class. No base class, no virtual, no `#include` of the manager. It does not know `ActiveStandbyBank` exists.

(lines 3-6) Its own `Config` struct and an array of two banks. (line 8) And here is the contract: `write` takes a `bank_id` as its *first* parameter, then whatever else this particular peripheral needs — here a field name and a value. (lines 9-18) The body is boring hardware code. (lines 20-23) And `commit` likewise takes a `bank_id` first.

So the entire implicit requirement is: "provide `write` and `commit` whose first parameter is a bank id". Everything after that is yours. A different peripheral could take a register offset and a 32-bit value, or three arguments, or none.

That flexibility is exactly what an abstract base class cannot give you — a virtual function has one fixed signature.

Generic abstraction layer

Register bank manager

ActiveStandbyBank implementation

template <typename REGISTER_ACCESS_LOGIC>
class ActiveStandbyBank
{
private:
	REGISTER_ACCESS_LOGIC m_register_access_logic{};
	uint8_t	m_active_id = 0;
public:
	explicit ActiveStandbyBank(REGISTER_ACCESS_LOGIC register_access_logic)
		: m_register_access_logic(std::move(register_access_logic)){}

	uint8_t active_id() const  { return m_active_id; }
	uint8_t standby_id() const { return (m_active_id + 1) % 2; }

	template <typename ...Args>
	bool write(Args&&... args)
	{
		return m_register_access_logic.write(standby_id(), std::forward<Args>(args)...);
	}

	template <typename ...Args>
	void commit(Args&&... args)
	{
		const auto current_standby_id = standby_id();
		m_active_id = current_standby_id;
		m_register_access_logic.commit(current_standby_id, std::forward<Args>(args)...);
	}
};

https://godbolt.org/z/zd5EG59P4

[1:15 — 39:35]

Now let's have a look at the ActiveStandbyBank implementation which is the star of the show.

It is 27 lines and it works with ANY register logic that satisfies the expected interface.

(lines 1-2) A class template over `REGISTER_ACCESS_LOGIC`.

(lines 4-6) It owns the register logic by value — no pointer, no indirection, and the compiler can see right through it — plus one byte of state: which bank is active.

(lines 8-12) Constructor, and the trivial bank arithmetic. This is the policy, written once.

(lines 14-18) `write`. This is the interesting part. We got our forwarding reference pack. Then on line 17, we call `m_register_access_logic.write` with the standby id and perfectly forward the arguments.

(lines 20-26) `commit` is the same shape. It grabs the arguments using a forwarding reference pack. It is to be noted that in our case the commit function took no argument so the parameter pack was empty. But that is ok.

Flexible and safe register accesses

Concept

Hardware is programmed through registers
Each register has fields of different sizes
Modifying a field is a generic read-modify-write (RMW) algorithm
Read the register, clear the field's bits, set the new value, write it back

For instance: ARM PL011 UART has a register called UARTLCR_H

Bits	Name
15:8	Reserved
7	SPS - Stick parity select
6:5	WLEN - Word length
4	FEN - Enable FIFOs

Bits	Name
3	STP2 - Two stop bits select
2	EPS - Even parity select
1	PEN - Parity enable
0	BRK - Send break

Flexible and safe register accesses

Goal

Provide a Register::write(...) function to write the fields
- Multiple fields can be written at once i.e multiple parameters
- We can choose how many field to write at once
- The order of parameters doesn't matter
Type safe

Client code

UARTLCR_H lcrh{registerAddress};

lcrh.write(
	// 8 data bits
	UARTLCR_H::WLEN{0b11},
	// enable FIFOs
	UARTLCR_H::FEN{0b1},
	// no parity
	UARTLCR_H::PEN{0b0}
);

UARTLCR_H lcrh{registerAddress};

lcrh.write(
	// enable FIFOs
	UARTLCR_H::FEN{0b1},
	// no parity
	UARTLCR_H::PEN{0b0},
	// 8 data bits
	UARTLCR_H::WLEN{0b11}
);

[1:35 — 42:00]

Here is what I want the API to look like. Requirements first, then the client code.

One `write` function. It must accept multiple fields at once — one read-modify-write cycle for the whole update, which for hardware is not just faster, it is *correct*: the register is never in a half-configured state. The order of the fields must not matter — they are named, not positional. And it must be type safe.

(fragment — left) So the client writes this. Each field is a small named object carrying its value: `WLEN{0b11}` for 8 data bits, `FEN{1}` to enable FIFOs, `PEN{0}` for no parity. It reads like the datasheet. No shifts, no masks, no hex constant you have to trust.

(fragment — right) And the same three fields in a different order does exactly the same thing.

Now — the type safety claim. What I want is for `UARTLCR_H::WLEN` and, say, `UARTCR::WLEN` to be different types, so that passing the wrong one is a *compile error*, not a silent corruption of a neighbouring field. That is the day-two-with-an-oscilloscope bug, and I want the compiler to catch it.

Let's build it. Two slides.

Flexible and safe register accesses

UARTLCR_H register definition

// Use CRTP to give the parent class the type of the register it abstracts
struct UARTLCR_H : public Register<UARTLCR_H> {
	UARTLCR_H(volatile uint32_t* regAddr):Register{regAddr} {}

	struct WLEN {
		using REG = UARTLCR_H;
		static constexpr uint32_t FIELD_OFFSET = 5;
		static constexpr uint32_t FIELD_SIZE = 2;
		static constexpr uint32_t FIELD_MASK = ((1 << FIELD_SIZE) - 1) << FIELD_OFFSET;
		uint32_t value;
		WLEN(uint32_t value):value{value} {}
	};

	struct PEN {
		using REG = UARTLCR_H;
		static constexpr uint32_t FIELD_OFFSET = 1;
		static constexpr uint32_t FIELD_SIZE = 1;
		static constexpr uint32_t FIELD_MASK = ((1u << FIELD_SIZE) - 1) << FIELD_OFFSET;
		uint32_t value;
		PEN(uint32_t value):value{value} {}
	};

    // Other fields implementation...
};

ℹ️ Each sub-structure implements the implicit requirements of the register abstraction

[1:30 — 43:30]

Let's first have a look at the UARTLCR_H register implementation.

(lines 1-2) We are using the CRTP pattern to tell the parent class the type of the register it abstracts. We will see in a moment how useful that is.

(line 3) Constructor takes the memory-mapped address.

Then we have our first field definition. Each field of the register will be a nested struct. The structure will have: a nested type. This type is actually the type of the register that the fields belong to. Three static constexpr values: the offset, the size, and the mask computed from them. And finally, a runtime `value` member which is the value that we want to write into the field.

Then we do the same for all the other fields, for instance PEN.

(fragment) The point: each nested struct satisfies the implicit requirements of the abstraction — a nested type `REG`, three static constexpr values, and a `value` member. That is the contract. And notice it includes a *nested type* — remember I flagged that back on the implicit requirements slide. This is where it pays off.

Flexible and safe register accesses

Register abstraction implementation

template<typename CHILD>
class Register{
private:
	volatile uint32_t* value; // Points to the actual memory-mapped register
public:
	Register(volatile uint32_t* regAddr):value{regAddr}
	{}

	uint32_t& operator*() {
		return *value;
	}

	template <typename ...FIELD>
	void write(FIELD... field)
	{
		static_assert((std::is_same_v<typename FIELD::REG, CHILD> && ...),
									"Using field from the wrong register");
		uint32_t curVal = *value; // Read value

		auto applyField = [&](auto f)
		{
			using FIELD_TYPE = decltype(f);
			curVal &= ~FIELD_TYPE::FIELD_MASK;                                        // Clear the field
			curVal |= (f.value << FIELD_TYPE::FIELD_OFFSET) & FIELD_TYPE::FIELD_MASK; // Set the field's value
		};
		(applyField(field), ...);

		*value = curVal; // Write back value
	}
};

👍 Any number of fields

👍 Fields order doesn't matter

💡 static_assert + <type_traits> ensure fields from the right register are used 💡

ℹ️ The fold expression executes the lambda for each field

[1:50 — 45:20]

Here comes the register abstraction. Let's go into it bit by bit.

(lines 1-2) First, we receive the child register type thanks to CRTP.

(lines 3-7) We then define some member variables, including a `volatile` pointer to the memory-mapped register.

We also take care of defining an operator* that will allow convenient access to the underlying register value.

Let's now have a look at the write function.

(lines 8-9) `write` takes a variadic pack of fields. That is how you get "any number, any order".

(lines 11-12) We enable type safety using static_assert and std::is_same_v. std::is_same_v checks whether the two types given as template arguments are the same. Thanks to the nested type REG of the field, and thanks to the CHILD template parameter, we can check at compile time that the field belongs to the correct register.

(lines 14-19) Finally we use read-modify-write to clear the field value and set it to the new one. In order to apply the algorithm to each value, we make use of a lambda from line 20 to 25. From the field type we can apply the right binary operation to achieve what we need. And finally on line 26, we use the fold expression to call the lambda on each field.

Flexible and safe register accesses

What does all of this cost?

The abstraction executes a lambda for each field...

uint32_t testValueAbstraction() {
	uint32_t v{0};
	UARTLCR_H lcrh{&v};
	lcrh.write(
		UARTLCR_H::WLEN{0b11},
		UARTLCR_H::FEN{0b1},
		UARTLCR_H::PEN{0b0}
	);
	return *lcrh;
}

uint32_t testValueDirect() {
	volatile uint32_t v{0};

	v = (v & ~0x72) | 0x70;

	return v;
}

Is the abstraction slower, faster or the same?

🙋‍♂️🙋‍♀️

Flexible and safe register accesses

True zero cost abstraction

uint32_t testValueAbstraction() {
	uint32_t v{0};
	UARTLCR_H lcrh{&v};
	lcrh.write(
		UARTLCR_H::WLEN{0b11},
		UARTLCR_H::FEN{0b1},
		UARTLCR_H::PEN{0b0}
	);
	return *lcrh;
}

testValueAbstraction():
		sub     sp, sp, #16
		str     wzr, [sp, 12]
		ldr     w0, [sp, 12]
		and     w0, w0, -3
		orr     w0, w0, 112
		str     w0, [sp, 12]
		ldr     w0, [sp, 12]
		add     sp, sp, 16
		ret

uint32_t testValueDirect() {
	volatile uint32_t v{0};

	v = (v & ~0x72) | 0x70;

	return v;
}

testValueDirect():
		sub     sp, sp, #16
		str     wzr, [sp, 12]
		ldr     w0, [sp, 12]
		and     w0, w0, -3
		orr     w0, w0, 112
		str     w0, [sp, 12]
		ldr     w0, [sp, 12]
		add     sp, sp, 16
		ret

https://godbolt.org/z/dfKK4nKoh

Conclusion: Key Takeaways

🔑 Template is a very powerful feature of C++
🔑 😈 Beware of the implicit requirements 😈
🔑 Replace your macros with templates
🔑 Generic programming
🔑 Allows extensibility
🔑 Good template abstraction can simplify client code without compromise on performance

Don't be scared of templates 👻

[1:45 — 47:55]

Let's wrap up. Six takeaways.

(1) Templates are a very powerful feature of C++ — and you have now seen that the powerful part comes from a handful of simple pieces, not from the scary ones.

(2) Beware of implicit requirements. They are the mechanism behind everything we built today, *and* the source of the worst error messages. Document them in comments, or state them with concepts if you are on C++20.

(3) Replace your macros with templates. The most actionable item on this list — you can do it this week.

(4) Generic programming: one implementation, many types, including types that did not exist when you wrote it.

(5) Extensibility — non-intrusive extensibility. New sink, new HAL, new register: you add code, you never modify the abstraction.

(6) And a good template abstraction simplifies client code without compromising performance. We proved that one with the assembly.

(fragment) So: don't be scared of templates. Start small — turn one macro into a function template this week. That is genuinely how it starts.

The end!

Questions?

🙋‍♂️🙋‍♀️

Slides available at: laurentcarlier.com/b2b-template-cppcon-2026/

[Q&A — 53:00 to 60:00]

KEY POINTS — prepared answers

Compile times? Real cost. Keep templates thin, push type-independent logic into non-template helpers, explicit instantiation when the type set is fixed. Measure first
When still virtual? Type set not known at compile time: plugins, heterogeneous containers, ABI boundaries. Compile-time polymorphism complements runtime, it does not replace it
Code bloat? Often overstated — the linker folds identical instantiations, inlining usually wins it back. Measure your binary
Concepts instead? Yes if C++20 — they make the implicit requirements explicit and the errors readable. Nothing today changes
All compilers? Godbolt uses GCC AArch64 -O2; same with Clang and MSVC. At -O0 of course not — zero cost assumes the optimiser is on
If Q&A dries up: offer to walk back through the register abstraction slide

Thank you. The slides, with every Godbolt and C++ Insights link, are at the address at the bottom.

Happy to take questions.

Goals of this presentation

Take home something you can use

Goals of this presentation

Template doesn't need to be complicated

Presentation philosophy

⏰ Agenda of today ⏰

Template syntax

Function template

Defines a family of functions

Function template

Defines a family of functions

Function template

Defines a family of functions 🔎

Function template

How are function templates compiled?

Function template

Implicit requirements

Template argument deduction

General

Template argument deduction

Type deduction

Template argument deduction

Explicit template arguments

Template argument deduction

How cv qualifiers are deduced

Template argument deduction

Arrays and pointers

Template argument deduction

⚠️ Why T& is dangerous with pointers ⚠️

When the deduced type surprises you

A generic myMax

When the deduced type surprises you

Fix: Provide a function overload

Putting templates to work

Generic programming

Putting templates to work

"Polymorphism" without inheritance

Variadic templates

A variable number of template parameters

Variadic templates

sum_all under the hood 🔎

Variadic templates

C++17's fold expressions

Variadic templates

Under the hood: one call per pack element 🔎

Perfect forwarding

Textbook example: std::vector::emplace_back

Perfect forwarding

The std::forward Catch

Class/struct template

Defines a family of classes

Perfect forwarding

The std::forward Catch reloaded

Class/struct template

Function member instantiation

Class/struct template

Curiously Recurring Template Pattern (CRTP)

Let's see templates in action

Generic serializer using a policy-based design

Generic serializer using a policy-based design

Generic abstraction layer

Register bank manager

Generic abstraction layer

Register bank manager

Generic abstraction layer

Register bank manager

Flexible and safe register accesses

Concept

Flexible and safe register accesses

Goal

Flexible and safe register accesses

UARTLCR_H register definition

Flexible and safe register accesses

Register abstraction implementation

Flexible and safe register accesses

What does all of this cost?

Flexible and safe register accesses

True zero cost abstraction

Conclusion: Key Takeaways

The end!

How `cv qualifiers` are deduced

⚠️ Why `T&` is dangerous with pointers ⚠️

A generic `myMax`

Textbook example: `std::vector::emplace_back`

The `std::forward` Catch

The `std::forward` Catch reloaded
